Ball Feeder Assemblies - cont'd
Indy500
World Shadw Corvet
Addam
Magic Who?
Part Number
Description
50026 50031 50032 50036 50038 50039 50044
Game and Part Quantity
A-19934
Ball Feeder Assembly
1
C-9638
Ball Shooter Lane Feeder Ass'y
1
Ball Feeder Assembly
A-19934
Item Part Number
1 01-13821
2.
01-9794
3 4008-01168-06
4 4406-01119-00
5 B-10932
6 03-7066-3
7 AE-27-1200
8 A-19936
9 10-437
10 04-10021.2
11 03-7655-4
Description
Ball Feeder Bracket
Flipper Stop Bracket
Mach. Screw, 8-32 x 3/8-
Nut
6-32
ESN
Solenoid Bracket Assembly
Coil Tubing
Coil Sub-assembly
Stop Ball Feeder Assembly
Kicker Spring,
Compo
Trough Assembly
HamessClip
5-8
