Wi reform , Ball Gate and Spin Target Locations
Item Part Number
Description
Item Part Number
Description
1 12-6842
Bottom Arch Wire Fence
7 A-19001
Ball Gate Assembly
2 12-7214.1
Left Wire Ramp
8
-A-19004
Race Track Assembly
3 12-7231
Wireform Ball Guide
a)
12-7226
Wireform Ball Guide
4 A-19521
Bumper Gate Assembly
9
A-19260
Center Wire Ramp Ass'y
5 12-7215
Garage Wire Ramp
a)
12-7212.2
Right Wireform
6
*A-19008
Engine Ramp Assembly
b)
12-7213
Center Wireform
a)
A-19002
Flop Gate Assembly
10 A-18982
Spin Target Assembly
b)
A-19099
Back Gate Assembly
11 A-19151
Upper Loop Switch Gate Ass'y
c)
A-19110
Front Gate Assembly
"See p. 3-42dg for Ramp Assembly drawing
-See p. 3-42d for Ramp Assembly drawing.
and p. 4-16d for Gate Assembly drawings.
