Page 267 - BallyMidway GREY Parts Catalog 16-9562-A

The SHADOW (50032)
Ramp Assemblies
7 r
A-17854
Item Part Number Description Item Part Number Description
1 A-17856.1 Small Ramp, Welded 8 8-12156 Single Flash Lamp Assembly
2 A-16909 opto Photo Trans Assembly 9 4106-01115-06Y SMS #6 x 3/8 PL-HWH-Yellow (2)
3 A-16908 opto LED Assembly 10 *31-2002-16 Playfield Plastic
4 4106-01013-08 SMS #6 x 1/2 P-PH-Type 25 (4) 11 01-13591.1 Fishpaper Opta Guard
5 A-19160-1 Ring/Cable Assembly 12 4700-00005-00 FW .141 x .437 x .032 (2)
6 4006-01168-06 MS #6-32 x 3/8 PL-HH-S 13 H-19661.1 Cable Assembly
7 03-8149-12 Mini Dome, Trans. Org. Peacock 03-7520-2 Ty-Wrap
"Not available individually. See p. 7-14 for set number.
(jJafPLt /MIDWAY
3-42c
