Backbox Circuit Board Locations
The ADDAMS FAMILY (50038)
Special Collectors Edition
Speaker/Display Panel
Playfield Circuit Board Locations
(Underside View in Raised position)
Item Part Number
1 C-139040
2 A-15576
3 A-151104
4 A-15113
5 A-15110
6 A-15139
7 A-15111
8 A-15112
9 A-104711
a) A-i.52.85
10 A-15542
Description
5-SwitchiDiode Assembly
Opto Sw-7 PC Board
4-lamp PC Board
o4-lamp PC Board
10-lamp PC Board
Hi-Powered PC Board
3-lamp PC Board
5-lamp PC Board
Hand Drive Assembly
Opto Sw-2 PC Board
Motor EMI Board (2)
Item Part Number
11 A-127042-50038
12 A-15028
13 A-12738-50038
14 A-15280
1.5 A-15416
16 A-104039
17 A-12697-3
Description
WPC CPU Board
Flipper Controller Board
WPC Sound Board
Single Flash lamp PCB
(3)
Extra Flipper Supply Board
Dot Matrix Controller Board
Power Driver PC Board
Mounted above the Playfield (See pp. 5-98 & 5-99):
A-14970-1 Book Case Assembly
A-15018
4-IR LED Board
A-15017
4-0pto Trans Board
18 5901-12784-00
19 0-12501
Dot Matrix Display/Driver Bd
7-lamp PC Board
Mounted in the Cabinet (See p. 2-4e for loeations):
A-14689-1
A-17316
WPC Coin Door Interface Bd
Opto Flipper Ass'y (2)
