CORVETTE (50036)
Playfield Circuit Board Locations
(Underside View in Raised Position)
(Top of Playfield)
Item Part Number
Description
Item Part Number
Description
1 A-19035
4-Lamp PC Board (4)
11 A-1900B
Engine Ramp Assembly
2 A-1243
Motor Driver Slave PCB/Brkt Ass'y
A-19155
2-Lamp Challenge Assembly
3 A-18159
10-0pto PC Board
12 A-19135
Engine Assembly No. 1
4 A-19037
9-Lamp PC Board
A-18951
Opto Full Engine PC Board
5 A-18753
Oulhole Ball Trough Ass'y
A-19175
Hall Effect Sensor Assembly
a)
A-18618
7-IR Trans PC Board
13 A-19177
Back Panel Assembly
b)
A-18617
7-IR LED PC Board
A-17713
3-Lamp
G.t
PC Board
6 A-19036
5-Lamp PC Board
A-17712
2-Lamp G.I. PC Board
7 A-1903B
2-Lamp PC Board (2)
B-12156
Single Flash Lamp PC Board
8 A-19039
3-Lamp PC Board
14 A-19004
Track Assembly
9 A-19242
Dual H-Drive/Bracket Ass'y
A-19141
Opto Board Assembly
a)
A-19159
Dual H-Drive Motor PC Board
A-1960B
Limits Oplo Board Assembly
10 A-17624
3-Lamp PC Board
15 A-19259
Xmas Tree Lamp
&
Brkt Ass'y
A-18B20
8-Lamp PC Board
(jJaI!&j
/MIDWAY
1-5e
