POPEYE
(50022)
Item Part Number
Description
~
A-~7624
3-lamp PC Board
2 A-17603
3-lamp PC Board
3
A-17602
18-lamp PC Board
4 A-15430
1O-Switch Oplo Board
5 A-16765
Outhole Trough Ass'y
a)
A-16927
7-Ball LED PC Board
b)
A-16926
7-Ball Opto PC Board
6
A-15542
Motor EMI Board
7 A-17623
Wheel Motor Assembly
a)
A-17069
3-8it Encorder PC Board
8
A-17600
5-lamp PC Board
A-17B53
2-lamp PC Board
(Mtd. under Upper Plfd)
9 A-12742-50022 WPC CPU Board Ass'y
10 A-15472
Fliptronic II Board Ass'y
11 A-16917-50022 WPC Audio Board Ass'y
12 A-14039
Dot Matrix Controller Bd Ass'y
13 A-12697-3
Power Driver Board Ass'y
14 5901-12784-00 Dot Matrix DisplaylDriver Bd
Speaker/Display Panel
(Rear View)
Not shown (See
p.
2-4 for Cabinet locations):
A-17316
A-H05H
Flipper Opto Board (2 used)
WPC Coin Door Interface Bd
Playfield Circuit Board Locations
(Underside of Playfield)
Backbox Circuit Board Locations
(jJafPLt
