C~f~~I!IfE
BLIIC/(
LACfJO
N.
(20018)
Ball Guide and Ramp Locations
Ball Guides and Deflectors
Item Part Number
Description
1 A·15616
Left Flipper Ball Guide
2 01-10768
Ball Guide
3 01-'0760
Ball Guide
4 01-10706
Ball Deflector
5 01-10772
Ball Guide
6 01-10763
Ball Guide
7 01-10761
Ball Guide
8 01-10771
Ball Guide
9 01-10822"
Right Ramp Wall Guide
10 01-10774
Ball Guide
11 01-11072
Ball Deflector Bracket
12 01-10770
Ball Guide
13 01-10767
Ball Guide
14 01-10773
Ball Guide
15 01-10707
Ball Deflector
16 01-10766
Ball Guide
17 01-10775
Ball Guide
18 A-15617
Right Flipper Ball Guide
to.
01-10708-1 Ball Guide Scoop
to.
01-10708-2 Ball Guide Scoop
Mounted under Bottom Arch (A-13204-20018):
19 B-8623
Runway/Baffle Guide
20 01-3569-1
Ball Return Runway
21 01-10599
Runway Ball Guide
Ramps and Troughs
A A-15620
B A-15609
C A-15621-1
D A-15622
E A-15619t
Plastic Ramp Ass'y
Left WalVRamp Ass'y
Plastic Ramp Ass'y
Plastic Ramp Ass'y
Plastic Trough Ass'y
"Used in conjunction with Ramp A-1560B.
"Used in conjunction with Ramp A-15619.
tMounted under Playfield.
