Page 143 - BallyMidway GREY Parts Catalog 16-9562-A

SEO Version

lilt
&
Level Assemblies - cont'd
8
/ '
/ '
/'
@
Tilt Switch
It
Cable Assembly
Tilt Switch & Cable Assembly
A·15487
A·17195
Item Part Number
Description
Item Part Number
Description
,
01-1168
Bumper Switch Bracket
1 01-1168
Bumper Switch Bracket
2 SW-1A-117
Tilt Switch
2 A-17238
Tilt Switch Assembly
3 01-96
Switch Limit Bracket
3 01-96
Switch Limit Bracket
4 01-3670-1
Switch Plate
4 01-3670-1
Switch Plate
5 4005-01003-12 MS 5-40 x 3/4 P-PH (2)
5 4005-01 003-12 MS 5-40 x 3/4 P-PH (2)
6 4405-01117-00 Nut 5-40 Hex (2)
6
4405-01117-00 Nut 5-40 Hex (2)
7 H-15478
Cable Asse,mbly
7 H-17196
Cable Assembly
8
5070-09054-00 Diode 1N4004 1.0A
Level
&
Mount Ass'y
A-15B02-P
(jJafPLt
/MIDWAY
2-18a
