Page 119 - BallyMidway GREY Parts Catalog 16-9562-A

Pinball Leg Assemblies
with Related Hardware
Crea Judge TwiZ Pop
Part Number Description 20018 20020 50020 50022
Game and Part Quantity
C~10843 Metal Leg Assembly
a) 01~2263~2 Chrome Finish 4
C~10843-1 Metal Leg Assembly
a) 01~2263~3 Epoxy Paint 4
C~10843-2 Metal Leg Assembly
a) 01-22634 Black Paint 4
C~10843-BR Metal Leg Assembly
a) 01-2263-2-BR Brass Plate 4
Related Hardware:
08-7377 Leg Adjuster 4 4 4 4
20-9492 Rivnut 4 4 4 4
4322-01125-40 Bolt 3/8-16 x 2·112 AH 8 8 8 8
Indy500 World Shadw Corvet Addam Magic Who?
Part Number Description 50026 50031 50032 50036 50038 50039 50044
Game and Part Quantity
A-19514 Leg Assembly, Chrome Finish 4 4 4 4
A-19514-2 Leg Assembly, Black Paint 4
C-10843-BR Leg Assembly, Brass Plate 4 4
Related Hardware:
08-7377 Leg Adjuster 4 4 4 4 4 4 4
20-9492 Rivnut 4 4 4 4 4 4 4
4322-01125-40 Bolt 3/8-16 x 2·112 AH 8 8 8 8 8 8 8
Note: See p. 2-6 for drawings.
(jJam; IM/DWAY 2-5
