Page 9 - Williams GREEN Parts Catalog 16-9932

INDIANA JONES (50017)
Printed Circuit Board Locations
(Underside View in Raised Position)
Item Part Number Description
Bridge Driver PC Board
la-Switch Opto Assembly
38-Lamp Combo Assembly
3-Lamp PC Board (2 used)
Opto Ramp Switch Board
Outhole Ball Trough Ass'y
7-0pto Photo Trans PCB
7-0pto LED PCB
Backbox Circuit Board Locations
13 14
A-15946
2 A-15430
3 A-167l6-2
4 A-16823
5 A-1390l·2
6 A-16765-1
a) A·17981
b) A·17982
Mounted above the Playfield:
A·16738 Motor Pivot/Drive Unit
A·166S7 Motor Oplo Switch Ass'y
A-16319 Right Plastic Ramp Assembly
A·1686l l·Flash Lamp PC Board
A-1670S Metal Ramp Assembly
A-16861 1-Flash lamp PC Board
A-16710 Right Ruins Assembly
A-16861 1-Flash Lamp PC Board
A-16707 Fighter Plane Assembly
A-16834 2 LED Flasher PC Board
I
Speaker/Display Panel
®
Item Part Number Description
7 A-15340 Motor EMI Board
8 B-12224 t-Larnp PC Board
9 A·16929·1 3-Bank Drop Target Ass'y
a) A-13609 3-Bank Oplo Board
10 A·16739 4-Lamp PC Board
11 A-12742'50017 WPC CPU Board
12 A-15472-1 Fliptronic II Board
13 A-16917-50017 WPC Sound Board
14 A-14039 Dot Matrix Controller Board
15 A·16l00 8-Driver"PC Board
16 A-12697-3 Power Driver PC Board
17 5901-12784-00 Dot Matrix DisplaylDriver Bd
Mounted in Ihe Cabinet (See p, 2-1 for locations):
A-14689
A-16484-1
A-16384
WPC Coin Door Interface Bd
Opto Flipper Ass'y (2 used)
Opto Flipper Switch PCB
1
