Ball Shooter and Ball Launcher Assemblies
India Star
Road Demo Flint
Dirty
Part Number
Description
50017 50023 50024 50028 50029 50030
Game and Part Quantity
A-14747*
Gun Handle Assembly
1
A-16113'
Gun Handle Assembly
1
A-16113-1·
Gun Handle Assembly
1
B-12445-1
Right Ball Shooter Assembly
1
w/10-148-1
Silver Spring
B-12445-7
Left Ball Shooter Assembly
1
w/10-148-7
White Spring
20-9663-8-4
"Launch Ball" Button Assembly
1
20-9663-B-7
"Rock Me" Button Assembly
1
"See Sect. 5, Unique Assemblies.
Ball Shooter
23-6327
Ball Shooter Assembly
8-12445-
·C ·
Retaining Ring
20-8718-1
Note: See p. 2-12 for Ball Launchers.
Shooter Spring
(See chart)
Machine Screw
4010-01006-10
Shooter Housing
21-6645
Flat Washer
4700-00051-00
Shooter Sleeve
03-7357
Rod Mtg Brkt
01-3535
Rod Spring
10-149
Shooter Rod
20-9253-7
