Page 326 - Williams GREEN Parts Catalog 16-9932

Unique Assemblies - cont'd
DIRTY HARRY (50030)
0
0
I o ! 11
Playfield Gun Motor Mtg. Ass'y
A-16581
Item Part Number Descri ption
01-13008 Gun Motor Bracket
2 A-19947 Motor & Crank Assembly
3 5647-12693-21 Mini-Micro Switch
4 4108-01031-14 SMS #8 x 7/8 P-TH T·25
5 03-8620 Actuator 19
6 A-18586 Drive Plate Assembly
7 01·8240 Nut Plate #2-56
8 4002-01105-07 MS 2-56 x 7/16 P-PH-S (2)
9 4700-00023-00 FW 13/64 x 518 x 16ga.
10 5070-09054-00 Diode 1N4004 1.0A
11 H-18600-3 Gun Cable Assembly
12 4008-01168-06 MS 8-32 x 3/8 Pl-HH-S
13 4008-01168-12 MS 8-32 x 3/4 Pl-HH·S (4)
14 4700-00133-00 FW 3/16 x 1-1/4 x 16ga.
15 01·8600 Insulator
16 01-13618 Gun Switch Bracket
17 4004-01003-05 MS 4·40 x 5/16 P-PH-S (2)
18 H-16437 Switch Cable Assembly
Associated Assembly:
19 A-18584.1 Bushing &. Welded Screw Ass'y.
18
RfD
CiJ'f~® ELECTRONICS GAMES, INC. 5-90
