Page 320 - Williams GREEN Parts Catalog 16-9932

(50029)
Unique Assemblies
Top View of Playfield
Item Part Number
A·18823
a) A·-17978
2 ·A-17796
Description
Back Panel Assembly
'Rock Slicer" Motor/Brkt Ass'y
Ball Gate Actuator Assembly (2)
"Used in conjunction with Ball Gate Assemblies A-18128
and A-18129. (See p. 4·29)
5
Underside View in Raised Position
Ball Gate Actuator Ass'y
A~17796
Item Part No. Description
1.
2.
3.
4.
S.
6.
7.
8 .
9.
01·12348
A·14406
A·11146
A·6892
10-120
4701·00003-00
4700-00089-00
4008-01021-07
10-194
Ba!! Gate Coil Brack.et
Coit Assembly
Armature Assembly
Frame & Eyelet Assembly
Spring
lockwa.sher, #8 Split
Flalwasher. 11/64 x 7/16 x 16ga
Mach. Screw. 8-32 x 7/16'
Extension Spring
5-84
