Miscellaneous Coil & Bracket Assemblies - cont'd
~
70
!
I
.;.
.
3
Coil & Bracket Assembly
A-19282
Item Part Number
Description
Item Part Number
Description
1
A-17808
Bracket & Stop Assembly
7b)
01-13625
Mounting Bracket Door
2 01-8-508-S
Coil Stop Bracket
c)
01-13268.1
Flap Door
3 A-14701
Coil Assembly
d)
01-13269.1
Link
4
03-7066
Tubing, 1.745" Long
e)
01-13270
Ball Deflector
5 4406-01119-00
Nut #6-32 ESNA
f)
02-5085
Pivot Pin
6 4006-01003-06
Mach. Screw, #6-32 x
31S"
g)
02-4731
Solenoid Plunger
h)
02-5084.1
Roller Door
Associated Assembly:
j)
07-6697-4
Rivet,
1/8
x 3/16"
k)
20-8716-5
Roll Pin,
1/8
x 7/16"
7 A-19132
Door Assembly
m)
20-8712-25
"Eft-Ring, 1/4" Shaft
a) A-19133.1
Door Sub-Assembly
0)
20-8712-43
"E"-Ring, 7/16" Shaft
