Diverter Assemblies - cont'd
Ramp Diverter Assembly
A-18585
Item Part Number
Description
Item Part Number
Description
1 A-19340.2
Divertor Mounting Plate
12 20-8712-43
"Eft-Ring,
7/16
H
Shaft
2 AE-26-1200
Coil Sub-Assembly
13 20-8716-5
Roll Pin, 1/8 x 7/16"
3 A-18583.1
Divertor Act. Shaft Assy.
14 4323-01158-06 SS
1/4-28
x 3/8"
4 A-11397
Slap Bracket Assembly
15 4004-01003-05 Mach. Screw, #4-40 x 5/16"
5 01-8413
Coil Mounting Bracket
16 07-6688-26
Rivet, 1/8 x
1/2H
6 02-4831
Shaft Divertor Actuator
17 4408-01119·00 Nut #8-32 ESNA
7 01-12993
Plate - Divertor Shaft Act.
18 01-13750
Coil Mounting Plate
8
01-13017
Divertor
19 31-2064
Decal- Top Ramp
9 02-5130
Shaft - Divertor Pivot
20 02-5048-2
M-F Spacer, 8-32 x
101/8"
10 03-7066
Coil Tubing
21 4700-00011-00 FW,
11164
x 7/16 x 16ga.
11 10-395
Spring
22 H·19775-1
Cable Assembly
O)f~®
ELECTRONICS GAMES, INC.
5-17
