Diverter Assemblies - cont'd
o
o
o
Ramp Diverter Assembly
A-17241
Item
Part
Number
Description
Item
Part
Number
Description
01-11957
Mounting Bracket
8
4701-00004-00 Lockwasher #10 Split (2)
2 A-12390
Stop Bracket Assembly
9 03-7066-5
Coil Tubing
3 01-7695
Solenoid Bracket
10 A-16636
Diverter Plunger Assembly
4 20-8790
Nyliner Bearing
11 10-303
Spring
5
A-20099
Coil Assembly
12 A-14185
Drive Arm Assembly
6 4006-01.017-04 MS 6-32
x
1/4 P-RH-S (2)
13 4010-01169-04 SS 10-32 x
1/4
SH-CP-N
7 401 0-01 066-06 CS 10-32
x
3/8
SH (2)
Diverter Assembly
A-17932
Item
Part
No.
Description
1 .
2.
3.
4.
5.
6.
7.
8.
01-12441
03-7067-5
01-8-508-T
AE-27-1200
10-135
A-,7986
23-6420
4008-01017-04
Diverter Post Bracket
Coil Tubing
Coil Retainer Bracket
Coil Sub-Assembly
Spring
Bell Armature Assembly
Rubber Grommet
Mach. Screw, #8-32 x
1/4"
6)f~®
