and the
flff[!§1T (b@.(!Jl§@f!J7@
(50017)
Ball Guide Locations
Bal! Guides
Item Part Number
Description
A-13204-500 17 Boltom Arch Assembly
2 A-16911-2
Left Flipper Ball Gd Ass'y
3 A-16974
Ball Guide Assembly
4
01-11757
Ball Guide
5
A-16931
Ball Guide Assembly
6 01-11768
Ball Guide
7 A-17168
Mini-Playfield Assembly
a) 03-8938
Left Ball Guide
b) 03-8937
Right Ball Guide
8
01-11307
Ball Guide
9 01-11308
Ball Guide
10 01-11519
Ball Guide
11 A-16492
Bal! Guide Assembly
12 A-16302
Diverter Ball Guide Ass'y
13 A-16493
Ball Guide Assembly
14 A-16487
Bal! Guide Assembly
15 01-11520
Ball Guide
16 A-16491
Ball Guide Assembly
17 01-11310
Ball Guide
18 A-16641
Ball Guide Unit
19 A-16911-1
Right Flipper Ball Gd Ass'y
20 01-11384
Ball Guide
A-1648B
Ball Guide Assembly
A-16489
Ball Guide Assembly
Mounted under Bottom Arch Assembly:
21 01-11387
Ball Guide
22 01-11385
Ball Guide
23 01-11386
Ball Guide
"Locations not shown - see p. 3-11 for drawings.
3-0
