Page 626 - Williams BLUE Parts Catalog 16-9064-B

Cashbox Assembly and Related Parts
for .Shuffle Alley Games
A-9712-Game #
<r7813-
Cashbox Cover/Bracket
12-6587-- _
Cashbox Handle
01-6224
Lock Bracket
.....•... ... --03-7626
, Plastic Cashbox
t---- 01-6389-1
Cashbox Nest
Strike Alley TicTac Gold Top
Part No. Description Zone Cats Strike Mine Dawg
1916 1918 1919 1920 1921
Game and Part Quantity
A-9712- Cashbox Assembly x x x x x
a) C-7813-1 Cover/Brkt Asy. (2 slot) 1 1
b) C-7813-2 Cover/Brkt Asy. (3 slot) 1 1
c) 01-6224 Lock Bracket 1 1 1 1
d} 01-6389-1 Cashbox Nest 1 1 1 1
e) 03-7626 Plastic Cashbox 1 1 1 1
f). 12-6587 Cashbox Handle 1 1 1 1
B-12322-1 Cashbox Assy. (3 slot) x
(Set\ p..9-0)
9-2
