Unique Parts for Specific Games - cont'd
BIG GUNS (557)
Cannon Assembly
pIn C·11641
Item Part No. Description Item Part No. Description
1 8-11640 Bracket Assembly 11 A-7438·1 Terminal Strip Assembly
2 23-6577 Plug Bumper 12 5070-06258·00 Diode, 1N4001, 1 A.
3 03-8089 Cannon Arm 13 4008-01017-04 Mach. Screw, 8-32 x 114
4 A-11769 Armature Link Assembly 14 4010-01066-06 Cap Screw, 10-32 x 3/8
5 02-4301 Cannon Arm Pin 15 4701-00004-00 lockwasher, #10 split
6 10-395 Spring 16 4004-01003-10 Mach. Screw, 4-40 x 5/8
7 01-4813 Bracket, Coil Mounting 17 4700-00104-00 Flatwasher, .316 x .5 x .0598
8 Al-23-800 Coil Assembly 18 26-8712-31 Retaining Ring
9 A-l0821 Coil Stop Bracket Assembly 19 03-7066 Coil Tubing
10 17-1067 Switch, Reworked
"Forcefield" Post Assembly
pIn C·118 19
Item Part No. Description
8-11662
2 B-11660
3 03-8090
4 01-8639
5 A-l0821
6 03-7257-11
7 10·399
8 10-401
9 10-392
10 01-8600
11 AE-23-800-0G
12 5647-12073-06
13 4006-01027-06
14 20-8716-18
15 4701-00024-00
16 4002-01005-06
17 4700-00103-00
18 20·8712-25
19 20-8790
20 4010-01006-08
21 4701-00004-00
22 5070-06258-00
Plunger Assembly
Main Frame Subassy
Flat Cam
Coil Support Bracket
Flipper Stop Brkt Assy
Post Bumper, Trans. Green
Spring, Compression
Spring, Extension
Spring, Compression
Insulator
Coil Assembly
IlSwilch w/roller
Mach. Screw, 6-32 x 3/8
Roll Pin
lockwasher, #2
Mach. Screw, 2·56 x 3/8
Flat washer, #12
E-Ring Retainer Clip
Bearing, Ny-lined .
Mach. Screw, #10-32 x 1/2
Lockwasher, #10
Diode, lN4001, 1.0A
