Unique Parts for Specific Games - cont'd
FIREI (556)
14
Ramp Lifting Mechanism
(pIn
8-11304 and associated parts)
Item Part No.
Description
Item Part No.
Description
1
A-11137
Lift Crank Assembly
15 4004-01003-05 Mach. Screw, 4-40
2 4406-01119-00 Nut, 6-32 ESN
16
Not Used
3 A-B050
Plunger Assembly
17 4008-01021-07 Mach. Screw, 8-32 x
7/16
4 4700-00073-00 Washer, .281 t.d. x ,500o.d. 18 4701-00003-00 Lockwasher, #8 Split
5
12-6227
Retaining Clip
19 4700-00089-00 Washer, .172 l.d. x
7/16
a.d.
6 10-128
Spring
20 8-11302
Lilt Mech Bracket Assembly
7 01-8-508-S
Coil Retaining Bracket
21 A-6892
Frame and Eyelet
8 4006-0101 7-06 Mach. Screw, 6-32 x 3/8
22 SM-26-600-DC Coil Assembly
9 AE-24-900-02 Coil Assembly'
23 A-11139
Armature Assembly
10 8-7572-1
8racket & Stop Assembly
a) A-8936
Armature Subassembly
11 4004-01003-10 Mach. Screw, 4-40 x
5/8
b) 01-8390
L Crank Lock
12 5070-06258-00 Diode, 1N4001
c) 4006-01003:03 Mach. Screw, 6-32 x
3/16
13 A-7438-1
Terminal Strip
24 10-363
Extension Spring
14 5647-12001-00 Microswitch
25 12-6227
Retaining Clip
5-28
ELECTRONICS GAMES. INC.
