EARTHSHAKER (568)
Wireform. Ball Gate and Spin Target Locations
Item Part No.
Description
1
12-6466-10
Wireform.
2-1/2"
2
A-12557
Ball Gate Assembly
3
B-12586
Spin Target Assembly
4
A-12589
Ball Gale Assembly
5
A-12500
Ball Gale Assembly
6
12-6813
Upper Right Wire Ramp
7
12-6814
Mid Right Wire Ramp
8
A-12506
Switch Gate Assembly
9
A-12558
Switch Gate Assembly
10 12-6812
Lower Right Wire Ramp
11 12-6466-6
Wireform,
1-1/2"
(2 used)
12 A-8645
Rollover Wire
&
Brkt Assy.
13 A-5844-44
Rollover Wire & Brkt Assy.
14 A-5844-45
Rollover Wire & Brkt Assy.
15 12-6542
Ball Return Gale Wire
16 12-6835
Bottom Arch Fence
ELECTRONICS GAMES. INC.
4-12j
