Page 185 - Williams BLUE Parts Catalog 16-9064-B

SWORDS OF FURY (559)
8all Guide and Ramp Locations
Item Part No. Description
1 8-12025 Left Return Frame
2 8-11945 Left Return Lane 8all Guide
3 C-11942 Ball Guide Assembly
4 B-11944 Ball Guide Assembly
5 C-11947 Ball Guide Assembly
6 B-11936 Ball Guide Assembly
7 01-6933 Ball Deflector
8 B-11939 Ball Guide Assembly
''6' 9 B-12002 Ball Guide Assembly
~
10 A-12003 Ball Guide Assembly
11 B-11237 Ball Guide Assembly
12 C-11943 Ball Guide Assembly
13 B-11949 Plastic Ramp
14 D-11869 Diverter Ramp
15 A-8108-R Right Return Frame
16 B-8623 Ball Guide & Baffle
0 17 01-3569 Ball Return Runway
00 0 18 C-8235 Ball Runway
00 0 0 0 19 31-1008-559 Screened Bottom Arch
0°° 0
ELECTRONICS GAMES. INC. 3-47
