Page 116 - Williams BLUE Parts Catalog 16-9064-B

Cabinet and Playfield Hardware for Pinball Games
--- , . . - - - - -
G-L Sor S-Sh Comt H-S R-K P-B F14 Mil
Part No. Description 523 532 535 540 541 542 549 554 555
Game and Part Q~_antity
A-9173-1 Plfd Holdown Asy 2 2 2
01-3493-1 C-Box Lock Brkt 1 1 1 1 1 1 1 1 1
-- ----
01-6389-1 C-Box Nest Brkt 1 1 1 1 1 1 1 1 1
' - - r- - - ----- .- -
01-8250 B-Box Hinge Bkt 2
- ------ '-------
20-9347 Toggle Latch 1 1 1
20-9518 Backbox Hinge 2 2 2 2 2 --,_ .• ..•.. _- ____ c.. __
$-St Taxi Fire B-G S-F eye Banz
Part No. Description 552 553 556 557 559 564 566
Game and Part Quantity
--.-. , -- -_ '- -- '- .-- -,-
01-3493-1 Cash Box Lock Brkt 1 1 1 1
-~
01-6389-1 Cash Box Nest Brkt 1 1 1 1
01-8726-L-1 Left Plfd Holder Brkt 1 1 1 1 1
01-8726-R-1 Right Plfd Holder Brkt 1 1 1 1 1 --
01-8897 Cash Box Cradle 1 1 1
20-9347 Toggle Latch 1 1 1 1 1
20-9518 Backbox Hinge 2 2 2 2 2 2
20-9555 Lockable Link Lock 1
(17-1096) (Reworked)
2-16
