C"8230 & C-82.70 FLIPPER ASSEMBL.IES
THIS DRAWING SHOWS RIGHT-HAND FLIPPERS
SEE TABLE FOR ALTERNATE PART NUMBERS
FLIPPER PARTS CORRELATION TABLE
FLIPPER ASSEMBLIES WITH FLIPPER ASSEMBLIES WITH
PART E.O.S. (END-OF-STROKE SWITCH) E.O.S. AND LANE-CHANGE SWITCH.
NUMBER C-8230-L C-8230-R C-8270-L C-8270-R
(Left Hand) (Right Hand) (Lett Hand) (Right Hand)
C-8231-L X , X
C-8231-R X X
SW-1A-139 j X
SW-1A-139-1 X I!
4104-01055-02 X X
4104-01055·09 X X
01-6924-L X X
01-6924-R X X
A-8232-L X X
A-8232-R X X
NOTE-C-8794 is a right-hand flipper which is identical to C-8230-R except that C-8231-R mounting bracket is
replaced with C-B293 mounting bracket which has one corner cut off.
A mini-flipper (part no. 20-9264) is used with C-8794_
SFL-19-400 130 -7~ O
COIL ASSEM8L Y
\ \-'iJ "..•.•.•... - •.. "'
5-3
