C-6296A (NEW) 10 STEP UNIT
FOR PIN GAMES, BOWLERS & SHUFFLE GAMES
WITHOUT PRINTED CIRCUIT & CONTACT RING.
20A-8712-18 3A-7126
IOA- 203 SW-II-MS
3A-7125
B·26·800
(204 VOLT)
8-28-1450
(50 VOLT)
A- 6293
IA-3459
20A-8712-25
SW-2U-12
SWITCH ADJUSTMENT:
AT "0" OR INDEX POSITION ALL
3 SWITCHES ARE OPEN AS SHOWN.
AT I ST TO 8 TH POSITION 2 TOP
SWITCHES ARE CLOSED. BOTTOM
SWITCH REMAINS OPEN.
AT 9TH POSITION ALL 3
SWITCHES ARE CLOSED. AS SHOWN.
OPEN
OPEN
OPEN
CLOSED
CLOSED
OPEN
CLOSED
CLOSED
CLOSED
6
