COIN TRIP SWITCH ASSEMBLIES
OLD TYPE
2A-2948
20A-8793
8-6291-1
•. FOR VENE 1.UEL A ORDER SWI TCH I tot -4
2A-2948
(BRASS)
2A-2953
2A-2998
(BRASS)
3A-7124
(NYLON)
NEW- 3 WAY COIN TYPE
IOA-201
A-6290
5W-IM-S 2A-2998
8-6591
USED ON "ALPINE CLU B"
& ALL fOLLOWING GAMES
WHEN ORDERING B-~591 SPECIFY COIN
DENOMINATIONS USED ON GAME .
COIN TRIP SWITCH ADJUSTMENT
WIRE (A) SHOULD BE IN
J CONTACT WITH SHAFT
(B) WHEN BLADE I ADJU:T~:~A~E
LONG BLADE SHOULD BE IN CONT ACT -~:__-- " "":I\
WITH NYL 'ON SWITCH ACTUATOR AND
HAVE A MAXIMUM OVER TRAVEL OF
1/3Z"
or
USING A GRAM GAUGE, TENSION OF
LONG BLADE SHOULD NOT EXCEED
10 GRAMS.
SWITCH ADJUSTMENT
1. FOR SMALL COINS, ADJUST SHORT BLADE SO
THAT THE 'GAP' BETWEEN THE SILVER CONTACTS
IS .030 TO .045.
Z. FOR LARGER &: HEAVI ER COINS THE 'GAP' SHOULD
BE .045 TO .060
3. DO NOT ADJUST 'GAP' CLOSER THAN. 030 74
