Page 217 - 1966_WMS_WILLIAMS_ASPIRE

2
12 11
4 ):_
13 ~ 16 15
~~j~ 17
27
~7
-- _19
~
28 / //' /
29 25 3
INDEX NO. PART NO. DESCRIPTION QUANTITY INDEX NO. PART NO. DESCRIPTION QUANTITY
I 200501 M"inplate Assembly 1 15 600563 Wire Cover 1
2 600526 Funnel 1 16 200516 10c Wa,he, Cutcher A•• embly 1
2A 600748 Fllnnel 1 17 600552 Hk Gate Spring 1
3 110-6-2 Sere..••. 4 18 600551 1Dc Gale Slop 1
4 600555 10c Push Rod Return Sp.ing I 1<) 110-6-3 Screw 1
5 600588 Washer 1 20 1OQ..8-6 Screw' 2
6 600442-4 Retain ing Ring 1 21 600549 25c Siring Catcher 1
7 110-6.4 Screw 2 2.2 600651 Switch Wire Retainer I
8 200512 lOe Gate Leyer Assembly 1 za 200507 25c Seporator Assembly 1
9 600448 Retaining Ring 1 24 600530 10c Thickness Gouge 1
10 200515 10c Wiper Auembly 1 25 600731 Washer 2
u 600543 lOe Gate Pivot Rod 1 26 600557 Deflector I
12 200504 lOe Gate Assembly J 27 600505 10c Mag net Brocket 1
13 600508 10c Undersize Roil 1 28 110-6-8 Screw I
14 600507 lOe Oversize Roil 1 29 200506 IDe Seporator Assembly 1
12
