(METAL)
B-6228 FLIPPER & COIL ASSEMBLY
Coil No's Printed in Block - SOY
Coil No's Printed in Red - 24V
Use Coil Chart Supplied With Each
Machine, When Ordering Coils.
8-6052 (METAU
A-4723 (PLASTIC)
FL 21-375 ---
28-400 Fl 25-930-31-600 1A-2S47 12A-6227
SPECIFY NAME
OF GAME
NOTE: IOA-127 RIGHT FLIPPER ASSEMBLY - SPRING
IOA-136 LEFT FLIPPER ASSEMBLY - SPRING
18-S-50S
METAL
B-6052 FLIPPER ASSEMBLY
PLASTIC
A-4723 FLIPPERASSEMBLY
6-32xl OVALHEAD
MACHINE SCREW
NOTE:
NOTE:
SPECIFY LARGE OR SMALL
• F III ON FLIPPER
B-6052 L - LARGE F
B- S052 R - Sh\ALL F
SPECIFY LARGE OR SMALL
"FiliON FLIPPER
3A-S007 L - LARGE F
3A- 6007 R - SMALL F
33
