Page 27 - 1964_WMS_PARTS_ASPIRE

(NEW) 10 STEP UNIT
C-6296 A
WITHOUT PRINTED CIRCU IT & CONTACT RING.
IOA-203
3A-7125
20A-8712-25 8-6292
SWITCH ADJUSTMENT :
AT "0" OR INDEX POSITION ALL
3 SWITCHES ARE OPEN AS SHOWN.
AT 1ST TO 8 TH POSITION 2 TOP
SWITCHES ARE CLOSED . BOTTOM
SWITCH REMAINS OPEN .
AT 9TH POSITION ALL 3
SWITCHES ARE CLOSED. AS SHOWN.
20A -8712 -18
6-26
800
IA-3459
5W-2U- 12
OPEN
OPEN
OPEN
CLOSED
CLOSED
OPEN
CLOSED
CLOSED
CLOSED
15
