Page 7 - 1962_WMS_PARTS_CATALOG_ASPIRE

WHEN ORDERING PARTS
1. Refer to the catalog and order all parts by number and de-
scription, specifying quantity and name of game for which
parts are being ordered.
2. Figure prices as quoted in the catalog. All prices are subject
to change without notice.
3. Returned merchandise will not be accepted unless previously
authorized.
4. All prices net F.O.B. our factory.
TABLE OF CONTENTS
Poge No.
100 STEP UNIT ••......•••.....•.... _.._ _.._._......................................... I
50 STEP UNIT (Resettingl... _ _ 2
50 STEP UNIT (Non.ResettingL ••••.....•................... _....................... 3
REPLAY UNIT. ...•......•..•.. _ _.....•.....•......... _ _ _._ 4
DRIVE ARM & PAWL ASSEMBLIES (50 Step) 5
100 STEP UNIT PARTS - WIPER ASSEMBLY 6
GEAR & SHAFT ASSEMBLIES (50 Step & 100 Step) ................•...•. 7
SNOWSHOE WIPER ASSEMBLIES (50 Step & 100 Stepl.. _ 8
10 STEP UNIT (With Contact Disc) 9
10 STEP UNIT (Without Contact Disc) ..............................•.... _.. _.__IO
10 STEP UNIT PARTS _ _ _........................•...........•......... II
RELAY BANK ASSEMBLY .•...•.... _._ __ _ _ 12
"JET" BUMPER ASSEMBLY •...........•.................................. _ 13
SWINGING TARGET ASSEMBLY_ ........•.•.........•...... _.........•.• _ 14
DISAPPEARING JET BUMPER ...........•................ _.......•..•....•........... 15
DISAPPEARING JET BUMPER ................••................................•.... 16
"E" RELAY ASSEMBLY ..... _.....•................................................••. I 7
"Z" & "M " RELAY ASSEMBLIES ..........•.................................... 18
LATCH RELAY ASSEM8L Y ..................•...................................•..... 19
BALL LIFT ASSEMBLIES ..........••....•............................................. ,,20
BALL LIFT ASSEM BLY & PARTS .•........•.•...... " 2 I
BALL SHOOTER s BALL RELEASE ASSEMBLIES 22
FLIPPER ASSEMBLY & PARTS ...................................•................. 23
BALL EJECT ASSEMBLlES .......•....................................... , 24
KICKER ASSEMBLY & PLUNGER ASSEMBL Y ....•................•.......... 25
KNOCKER ASSEMBLY & SHOOTER COIL ASSEMBL Y 26
BELL & BELL ASSEMBLIES 27
SOLENOID PLUNGERS 28
COIL REPLACEMENT SLEEVES .•............................................ ".29
SWITCH ASSEMBLIES ........................•..........................••.............. 30
CAM FOLLOWERS & SWITCH BLADES .....•................................... 31
Page No.
SWITCH ASSEMBLY PARTS 32
WIRE FORMS ..•............................................•................ · 33
PLAYFIELD ARCHES _ 34
SLUG REJECTOR MOUNTING s PARTS 35
CABINET PARTS 36
CABINET PARTS 37
INSERT HINGE - MISCELLANEOUS PARTS... . 38
ROAD RACER - STEERING WHEEL ASSEMBly...... .. 39
ROAD RACER - STEERING MECHANISM .......•............. .40
ROAD RACER - TIMER MOTOR - CAR ASSEMBLy .4 I
ROAD RACER - DRUM MOTOR & PARTS 42
ROAD RACER - MISCELLANEOUS PARTS .43
POOL TABLE - MISCELLANEOUS PARTS .. .44
PITCHER UNIT ASSEMBLY (Official Baseball) _.45
BALL TRACK ASSEMBL Y .....................•...................................... 46
PITCHER UN IT ASSEMBL Y 47
PITCHER UN IT ASSEM BLY _.............. , 48
BATTER UNIT ASSEMBL Y " 49
BAT HANDLE LEVER ASSEMBL Y......................... .. 50
BAT HAN DLE LEVER ASSEM BLY (J 957 Boseba II) 5 1
MAN RUNNING UNIT ASSEMBLY _.............. . ,52
BALL PLAYER ASSEMBLIES , 53
BASEBALL MISCELLANEOUS PARTS . . 54
RIFLE ASSEMBLY & PARTS ... 55
GUN GAME PARTS .. 56
GUN GAME PARTS " 57
BOWLER MANNIKIN & PARTS.. .' .. 58
BOWLER - MISCELLANEOUS PARTS . 59
HORSE GAME - PARTS .. 60
PRICE LISTING - (Arranged by Group of Related Ports) .. 61·66
PRICE LlSTIN:; - (Arranged in Numericol Order) 67·74
