Page 590 - BallyMidway YELLOW Parts Catalog 16-9147-B

SEO Version

5647 -12073·14
5647-12073-17
Mini-Micro Switches and Associated Assemblies - cont'd
5647-12073-21
5647-12073-31
Switch
Used on
Trck Game Atla Tran Mous Elvi
Part Number
Assembly Part No.
2001 2003 2006 2008 2009 2011
Game and Switch Quantity
5647-12073-14
A-12172
1
1
Lane Change Sw. Assy.
A-12172-1
1
1
Lane Change Sw. Assy.
5647-12073-17
A-12909
1
Switch/Diode Assy.
5647-12073-21
8-12672
1
Wire Ramp Assy.
0-12620
2
Plastic Ramp Assy.
5647-12073-31
A-13238
1
Switch/DJode Assy.
6-22
@a!fy/MIDWAY
