THE ADDAMS FAMILY (20017)
Dlverter Assembly
A-1S040
It8m Part Number
1.
A·15041
2.
20-8790
3.
03·7066
4.
01·8413
5.
AE·26·1500
6.
A·l0821
7.
4010-01008-06
8.
4701-00004·00
Associated Parts
9.
10.
11.
A·13278
A·14185
A·15039
Description
Mounting Bracket
Nylined Bearing
Coli Tubing
Col Mounting Bracket
Coil Assembly
Flipper Stop
8
racket Assy.
Mach. Screw,
10·32
x
3/8
Lockwasher
#10
Split
Plunger Assembly
Orlve Arm Assembly
Oiverter Assembly
Klckout Assembly
A-1S200
Item Part No.
DescriptIon
Kickout Sub-Assembly
Coil Tubing
Coil Assembly
Coil Bracket Assy.
Nut
8·32 ESN
Solenoid Spring
Bell Armature Assembly
Rubber Grommet
Switch
Mach. Screw,
2·56
x
7/16P·PH·S
DIode
1N4004
Nul Plate
Coil Bracket· Front
Mach. Screw,
8·32
P-PH-S
Insulator
5-108
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
A·15201
03·7067
AE-23-800
01·9423
4408-01119-00
10-135
A-13270
23·6420
5647·12693·25
4002-01105-07
5070·09054·00
01·8240
A-15376
4008·01003·06
01·8600
