Page 538 - BallyMidway YELLOW Parts Catalog 16-9147-B

Unique Parts for Specific Games - cont'd
BLACK ROSE (20013)
Ball Popper Assembly
0-113:J5..1
Description
Bracket Assembly
Armature Assembly
Ball Popper Cap
Dowel Pin, 3132x 112-
Mounting Bracket
Coil Assembly
Rubber Grommet
Spring
Mach. Screw, #8-32 x 5116
Coil Tubing
Itam Part Number
1. B-11631
2. A-11336
3. 03-8053
4. 20-9314-7
5. 01 -9794
6. AE-24-900
7. 23-6420
8. 10-135
9. 4008 -01017-04
10. 03-7067
: ~--i 6
Switch Membrane
5641-12673-00
To Switch & Diode PCB, C-13940
(Mtd. in Cabinet)
@a!fy/MIDWAY
5-102
