DR. WHO (20006)
5-Target
Assembly
A-15500
hem Part Number
Description
1 03-8654
Target (5)
2
03-8655
Base
3
10-298
Plunger Return Spring (5)
4
20-8713-25
"C· Ring
1/4"
Shaft (5)
5 A-15432
S.IR LED Board
6 A-15431
5-0pto Board
7
H-15592
Cable Assembly
8 41 04-01 00 1-06
SMS #4 x 3/8 P-PH-A (8)
~J __
Back View
Back Panel Assembly
A-15501
Item Part Number
Description
1 6-12224
Single Lamp Assembly
2
A-12336-1
Socket & Bulb Assembly
3
CW~OO22-4
Wire 22AWG, Yellow
4
11-831-20006
Wood Back Panel
5
31-1681-12
Playfield Plastic
6 4106-01114-08
TCS #6x112 PL-HWH
7
4106-01033-08
3M3
#6x1/2
P-TH-A
8
03-7655-4
Harness Clip
1/4-
9
H-15515
Back Panel Cable Ass'y
