Unique Parts for Specific Games ~cont'd
Dr. Dude (2016)
o
4
Gear Assembly
0-13793
Item Part No.
Description
1 01-9710
Bracket Mounting
2
C-13794
Gear/Post Assembly
3
03-8434
Pinion
4
02-4419
Adjusting Screw
5
03-8347
Gland
6
20-9610
Bearing Flange
7
03-8363
Nut locking
B
14-7955
Motor
9
4008-01017-0B
Mach. Screw, 8-32 x 1/2
10 4108-01 004-06
Sh. Metal Screw, 8-32 x
3/8
11 4700-00016-00
Flatwasher,
3/16
x
7/16
x 17 gao
12 20-9639
Metric MS Screw
13 4006-01 076-04
Set Screw, 6-32 x
1/4
14 A-9302·
Socket & lamp Assembly
a) 24-8704
Bulb #89
15 4006-01003-04
Mach. Screw, 6-32 x 114
16 4406-01119-00
Nut, ESNA 6-32
