Page 503 - BallyMidway YELLOW Parts Catalog 16-9147-B

2
Unique Parts for Specific Games - cont'd
Dr. Dude (2016)
Big Shot Kicker Assembly
A-14098
item Part Numbe r
1 A·14099
2 A-14101
3 A-8050-1
a) 02-3407-2
b) 03-8085
c) 20-8716-5
4 12-6227
5 4700-00030-00
Associated Assembly:
Item Part Number
6 B-11203·R·1
a) 8-7572-1
b) AE-26-1500
c) 01-8-508-S
d) 03-7066
e) 4006-01017-06
f) 4406-01119-00
g) 10-128
1
Description
Crank Assembly
Kicker Mounting Bracket
Plunger Assembly
Plunger Coil, 2-1/8~
Armature Link
Roll Pin, 1/8 x 7/16
Hairpin Clip
Flatwashar, 17/64 x 112 x 15ga.
Description
Coli & Bracket Assy
Bracket Assy
Coil Assy
Coil Relainer
Coil Tubing
Mach. Screw, 6·32 x 3/8
Nut, 6-32 ESN
Spring
@af!tt/MIDWAY 5-69
