Page 498 - BallyMidway YELLOW Parts Catalog 16-9147-B

Unique Parts for Specific Games - cont'd
Pool Sharks (2014)
Shark Assembly
8-13466
Item Part Number Description
1 01-9552 Mounting Clip
2 07-66SS-1SN Rivet 1IS x 3/16 (2)
3 12-6901 Actuator Wire
4 31-1006-2014-20 Screened Plastic
5 31 -1006-2014-13 Screened Plastic
6 4006-01005-08 MS 6-32 x 112P-PH
7 4406-01119-00 Nut 6-32 ESN
8 4700-00009-00 FW .172 x .437 x .032
Related Assembly: Coli Bracket Ass'y B-13579
4 Item Part Number Description
01-9224 Coil Mounting Bracket
2 A-129sa Frame & Eyelet Ass'y
3 4006-01048-05 MS #6-32 x 5/16 SL-HWH (2)
4 A-11146 Ball Gate Armature Ass'y
5 10-96 Compression Spring
6 SMZ-35-4000-DC Coil Assembly w/Oiode
7 470o-o0OS9-0o FW .172 x 7/16 Brass
8 4701-00003-00 Split Lock Washer #8
9 4008-01021-07 MS #8-32 x 7/16 PH-R
5-64 @a!fy/MIDWAY
