Page 492 - BallyMidway YELLOW Parts Catalog 16-9147-B

Unique Parts for Specific Games ~cont'd
MOUSIN' AROUND (2009)
,
Transfer Tray Assembly
C-12923
Item Part Number Description
1 20-8712-25 "E" Ring 1/4" Shaft
2 B-12954 Ball Transfer Tray Assy.
3 4701-00024-00 Lockwasher #2 Split (2 used)
4 4002-01005-06 MS #2-56 x 3/8 P-PH (2 used)
5 A-11991 Mini Switch Sub-Assy.
6 4006-01048-05 MS #6-32 x 3/8 HWS (4 used)
7 C-13061 3-Switch PC Board Assy.
8 A-130BO Ball Tray Assembly
9 20-8790 Nylined Bearing (4 used)
10 01-9365 BalI Retainer Bracket
5-58 @a!fy/MIDWAY
2
