Page 479 - BallyMidway YELLOW Parts Catalog 16-9147-B

Unique Parts for Specific Games - cont'd
ATLANTIS (2006)
Top View ®
3 I
I
I
2
5
II
Bottom View
Sub Platform Assembly
C-12571
lIem Part Number Description Item Part Number Description
1 11-897 Wood Platform 5 01-9150 Clip Hold Down Brkt. (2)
2 B-12647 Knocker/Sub Assembly 6 02-4366 WS Post#S
a) A360-00046-0000 Coil & Tubing Assy. 7 A-12736 Mini-Micro Sw. Assy.
b) A360-00011-00XF Plunger/Striker Assy. 8 0012-00010-2400 Bushing (2)
c) 01-9277 Coil Bracket 9 03-6047-15 Spacer 1~
d) 01-9016 Coil Frame 10 03-6047-16 Spacer 1-1116~
e) 0010-00274-0212 Compression Spring 11 4106-01 001-07 8MS #6 x 7/16 P-PH (2)
f) 4008-01015-04B rr #8-32 x 1/4 P-PH 12 4106-01 001-24 8MS #6 x 1-1/2 P-PH (2)
g) 4705-00002-00 Spring Washer 13 4106-01 022-12 SMS #6 x 314P-R (2)
3 A-12765 Ball Gale Assembly 14 4700-00011-00 FW .172x.437)(.059
4 4106-01115-07 SMS #6 x 7/16 PL (2)
@af!tt/MIDWAY 5-45
