Unique Parts for Specific Games ~cont'd
GAME SHOW (2003)
7
Multi-Bail Kicker Assembly
(Ball Locker)
C-13386
Item Part Number
Description
1
A-13270
Armature Assembly
2
AE-23-800
Coil Sub-Assembly
3
01-8-S08-T
Solenoid Bracket
4
01-8918
Coil Mounting Bracket
5
10-135
Solenoid Spring
6
03-7067-5
Coil Tubing
7
23-6420
Rubber Grommet
8
4008-01 017-04
MS #8-32 x .25 P-RH
I
4
®
Item Part Number
Description
1 4008-01016-08
MS #8-32 x
1/2
P-RH
2 8-13307
Extension Bracket Assy.
3 4408-01119-00
Hex Nut 8-32 ESN
4
D-11335-2*
Ball Popper Assembly
5 A-12792
Switch & Diode Assy.
6 01-3670·1
Switch Plate
7 4005-01051-10
MS #5-40 x 5/8 SL-RH
Ball Popper
&
Extension Assembly
0-13306
2
®....
(]'f"
5
4
*See p. 5-49 for drawing
&
parts list of Ball Popper Assembly.
@af!tt/MIDWAY
5-41
