Page 473 - BallyMidway YELLOW Parts Catalog 16-9147-B

8-13380
Unique Parts for Specific Games - cont'd
GAME SHOW (2003)
- ~ ~ - - _,--
Coli & Bracket Assembly
(For Top Ramp Gate)
Item Part Number Description
1 01-9527 Mounting Bracket
2 A-12948 Frame &. Eyelet Assembly
3 4006-01003-05 MS #6-32 x .31 P-PHS
4 A-13381 Ball Gale Armature Assy.
5 10-120 Compression Spring
6 SM2-35-4000 Coil Assembly wlDiode
a) 5070-06258-00 Diode 1N4001 1.0A
7 4700-00089-00 Flat Washer .172
8 4701-00003-00 Split Lock Washer #8
9 4008-01021-07 MS #8-32 x .44 P-RH
