Page 471 - BallyMidway YELLOW Parts Catalog 16-9147-B

3
Unique Parts for Specific Games - cont'd
TRUCK STOP (2001)
11
Lane Change Mechanism Assembly
A365-07500-0008
Item Part Number Description
1 A967-00011-0000 Core Plug & Bracket Assy.
2 A967 -00046-0000 Coil & Tubing Assembly
a) 5070-09054-00 Diode 1N4004GP 1.0A
3 0017-00104-0073 Spring Washer .515 i.d.
4 0360-00318-00XF Coil Bracket
5 0010-00274-0212 Compression Spring
6 0967-00701-00XF Plunger
7 0017-00101-0115 Retaining Ring .484
8 0967 -00901-0000 Slingshot Kicker Arm
9 20-8790·5 Nyliner Bearing
10 0967-00130-00XF Mounting Bracket
11 0365-03000-0010 Lane Change Bracket
12 0365-1 7042-1 902 Lane Change Kicker Arm
13 0017-00101-0202 MS #8-32 x 1/4 PH
@af!tt/MIDWAY 5-37
