Page 462 - BallyMidway YELLOW Parts Catalog 16-9147-B

SEO Version

Plunger Assemblies ~cont'd
Plunger Assembly
A·13278
Item Part Number
Description
1 02~4241
Coil Plunger
2 10-389
Gate Mch. Spring
3 20~8716~5
Roll Pin 1/8.x 7/16
4 20~8712-43
"E" Retaining Ring
4
Armature & Extension Assembly
A-14585
Item Part Number
Description
1 A-11344
Armature Sub-Ass'y
2 20~8716-20
Roll Pin
1/8
x
3/8
3 03-8560-1
Extension Shaft
Plunger Assembly
A-15175
Item Part Number
Description
1 02-4595
2 20-9370-1
3 03-8050-1
Coil Plunger
Spring Pin
Armature Link
Plunger Assembly
A-15370
Item Part Number
Description
1 A-11334
Armature Sub-Ass'y
2 03~8669
Plunger Extension
3
20-8716-20
Roll Pin
1/8
x
3/8
5~32b
