Page 412 - BallyMidway YELLOW Parts Catalog 16-9147-B

Ball Eject Assemblies - cont'd
B-9361-R B-9361-R-1
Item Part Number Description Item Part Number Description
1 A-6949-R Spring Plate 1 A-6949-R Spring Plate
2 A-7471-R Eject Cam 2 A-7471-R Eject Cam
3 A-S050 Plunger Assembly 3 A-S050-1 Plunger Assembly
a) 02-3407 Armature Link a) 02-3407-2 Armature Link
b) 03-8085 Coil Plunger b) 03-8085 Coil Plunger
c) 20-8716-5 Roll Pin 1/8 x 7/16 c) 20-8716-5 Roll Pin 1/8 x 7116
4 A-8268 Mtg. Bracket Assy. 4 A-826B Mtg. Bracket Assy.
5 10-362 Eject Spring 5 10-362 Eject Spring
6 12-6227 Hairpin Clip (2 used) 6 12-6227 Hairpin Clip (2 used)
7 4700-00030-00 FW .265x.SOOx.067 7 4700-00030-00 FW .265x.SOOx.067
8 4700-00103-00 FW .265x.500x.015 B 4700-00103-00 FW .265x.500x.015
9 AE-23-800 Coil Assembly 9 AE-23-800 Coil Assembly
10 03-7351-'-9 Eject Shield, Tr. Red 10 03-7351-1-9 Eject Shield, Tr. Red
5-2 @a!fy/MIDWAY
