Printed Circuit Boards Located Under the Playfield for Pinball Games
Trck Game AUa Tran Mous Elvi
Description
Part No.
2002 2003 2006 200S 2009 2011
Game and Part Quantity
C·11902-1
1
1
Relay Boards
C-1199S·1
1 1 1
C-12587
2
3-Bank Opto Bd.
C·12559
2
1
Back Panel Boards;
3·lamp PCB
C·12553
1
Backboard PCB Asy C·13061
1
3-Lamp PCB
C·13066
1
Rgt 8-Lamp PCB
C·13353·1
1
Lft a-Lamp PCB
C·13353·2
1
s-tamp
PCB
C·12937
1
10-Lamp PCB
C·12436
1
Notes:
1.
Parts lists for the above Lamp Boards are available in individual
game manuals.
2. To locate a part under the Playfield, refer to the drawings for each
game at the beginning of this section.
Printed Circuit Boards located under the Bottom Arch
TRUCK STOP (2001)
4·Pos. Detector PCB
pIn
A084·91894-COOO
4-Pos. Emitter PCB
pIn
A084·91895-COOO
