Page 26 - BallyMidway YELLOW Parts Catalog 16-9147-B

MOUSIN' AROUND (2009) - cont'd
Backbox Circuit Board Locations
I D,
e- r}--- 1-':
I
1 I
'i I
I
i
~
- I - -
®-
I I
~
I
( j ) -
~ U -
®
Item Part No. Description
7 0-12313-2009 Backbox Interconnect Bd.
8 0-11883-2009 CPU Board System 11B
9 0-11581-2009 Audio Board
10 0-12246 Power Supply Board
11 0-12247-2009 Aux. Power Driver Bd.
12 0-12502-1 Right Display Board
13 0-12706 Left Oisplay Board
14 C-13120 7-Lamp Board
15 C-11998-1 Relay Board
Master Display Board Locations
(Rear view of Display Panel)
Insert Circuit Board Locations
(Viewed in open position)
1-8 @a!fy/MIDWAY
