ATLANTIS (2006)
Playfield Circuit Board Locations
(Underside of Playfield)
Backbox Circuit Board Locations
~.
e-
bl~
f-©
I
I
I
,_.
I
I
I
,
!
.@r
J
-r
-@
(£-
I
i
i.
@
Item Part Number
Description
1
C-12550
4-Lamp Board Assy.
2 C-12551
3-Lamp Board Assy.
3 C-12548
3-Lamp Board Assy.
4 C-12587
Relay Board
5 C-12554
9-Lamp Board Assy.
6 C-125S2
5-Lamp Board Assy.
7 C-12549
5-Lamp Board Assy.
8 C-12553
3-Lamp Back Panel Bd.
Insert Circuit Board Location
9 A084-91786-2006
Control Board
(Viewed in open position)
10 A084-91901-2006
Fuse Board
11 0-11581-2006
Audio Board
12 C-12417
Sound Interface Board
13 C-9939-554
Flipper Power Supply
14 A084-91785-2006
Main Power Supply
15 B084-91851-HOOO Dual Display Modules
16 C-12587
Relay Board
