Page 20 - BallyMidway YELLOW Parts Catalog 16-9147-B

GAME SHOW (2003)
Playfield Circuit Board Locations
(Underside of Playfield)
Item Part No. Description
1 C-13366 3-Lamp Board Assy.
2 C-13365 5-Lamp Board Assy.
3 C-13352 12-Lamp Board Assy.
4 D-13367 21-Lamp Board Assy.
5 C-13368 4·Lamp Board Assy.
6 C·13364 4-Lamp Board Assy.
7 C-11902-1 Relay Board
8 C-13353-1 Righi Lamp PCB Asy.
9 C-13353-2 Left Lamp PCB Asy.
0 B-12224 Single Lamp PCB
