Page 195 - BallyMidway YELLOW Parts Catalog 16-9147-B

SEO Version

Item Part No.
Description
1 31·1008·2009
Screened Bottom Arch
a)
01-9366-2
Bottom Arch Extension
2 B·12852
Left Ball Return Frame
3 B-12850
Left Exit Ball Guide Asy.
4 0-12830
Left Ramp Assembly
5 0-12848
Ball Guide Assembly
6 R·12829
Multi-Ramp Assembly
7 A-13275
Ball Guide/Ramp Support
8 B-13058
Vertical Ramp
9 A-12849
Ball Guide Assembly
10
8-12853
Ball Guide Assembly
11 A-12855
Ball Guide Assembly
12 C-13026
Center Ramp Assembly
13 A-12856
Ball Guide Assembly
14 A-12851
Right Ball Return Frame
Under Bottom Arch:
15 B-8623
Ball Guide
&
Baffle Asy.
16 01·3569-1
Ball Return Runway
17 C-8235
Ball Runway Assembly
Ball Guide and Ramp Locations
@af!tt/MIDWAY
(2009)
3-5
