Page 156 - BallyMidway YELLOW Parts Catalog 16-9147-B

Description
Knocker Assembly
A-15267
Part Numbar
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
A-15266
23·6420
A-13270
10-135
4408-01119-00
01·9423
AE-23-800
03-7067
23-6629
H-11835
Pool Radic Dude Harl Bugs
Knocker Assy. Part No. 2014 2015 2016 20001 20009
8-10686-1 x x x x x
Knocker Assembly Gillign ParfyZ DrWho B!ackRTAddam
Part Number 20003 20004 20006 20013 20017
A-15267 x
8-10686-1 x x x x
Note: Knocker Assembly for Addams Family (20017) is mounted on the
right side wall of the Cabinet.
Item
2-14d
Knocker Bracket Assy.
Rubber Grommet
Bell Armature Assembly
Solenoid Spring
Nut 8-32 ESN
Coli Bracket
Coil Assembly
Coil Tubing
Bumper Pad
Cable
@a!fy/MIDWAY
